ZeroMQ Message Statistics

Server uptime in seconds

1 ZeroMQ Servers

/etc/service/msgqueue1: up (pid 14595) 241201 seconds
/etc/service/msgqueue2: up (pid 20737) 37865 seconds
/etc/service/msgqueue3: up (pid 8186) 370804 seconds
/etc/service/pubsub-freetier: up (pid 449) 531569 seconds
/etc/service/rd: up (pid 1379) 532342 seconds

1.1 Diagram

In the following diagram, the tictacqt client (shown in blue) makes a random connection to one of the three msgqueue servers (in this case msgqueue1). There is also a PUB/SUB broadcast server connection that is made, to observe games and retrieve moves that are played.

Finally, a backend server called the routerdealer or rd for short handles the majority of the commands. It is also the primary means through which messages are broadcast out to all the clients, by sending messages to the pubsub_freetier. The purpose of the msgqueue instances is that they contain an additional SendMsg command, which can send a message directly to another tictacqt instance that is connected to it.

1.2 Broadcast heartbeat

The broadcast service will send out a heartbeat message every 2 seconds. Clients can reconnect if too much time has elapsed, between heartbeat messages.

1.3 Response time graphs (msgqueue)

These response time graphs show the result of a ping request, through the ZeroMQ protocol, via the msgqueue instances. The request reaches a msgqueue instance, then traverses as a new request to the routerdealer, resulting in a response that is passed back. Samples are made every minute.

15min

Hour

4-Hour

Day

1.4 Response time graphs (direct to routerdealer)

This next set of response graphs bypass the msgqueue instances and just communicate directly with the routerdealer. The response times in comparison can be measured to be slightly quicker, since there is one less round trip.

15min

Hour

4-Hour

Day

1.5 Response time graphs (broadcast)

This is the pubsub broadcaster response time, in microseconds. Samples are made every minute. The test consists of picking up the next available heartbeat message from the service.

15min
